Double Layers Hydraulic Rubber Vulcanizing Press Machine Automatic Control

Double Layers Hydraulic Rubber Vulcanizing Press Machine Automatic Control
Double Layers Hydraulic Rubber Vulcanizing Press Machine Automatic Control Double Layers Hydraulic Rubber Vulcanizing Press Machine Automatic Control

Large Image :  Double Layers Hydraulic Rubber Vulcanizing Press Machine Automatic Control

Product Details:
Place of Origin: QINGDAO CHINA
Brand Name: RUNNING
Certification: ISO CE
Model Number: XLB-D400*400*2/0.50MN
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Packaging Details: Fumigation-free package
Delivery Time: 21~30days
Payment Terms: T/T, L/C
Supply Ability: 50sets/month

Double Layers Hydraulic Rubber Vulcanizing Press Machine Automatic Control

Description
Clamping Force: 50T Heating Plate: 400*400mm
Daylight: 150mm Stroke: 300mm
Driving Motor: 2.2kw Name: Rubber Vulcanizing Press Machine
High Light:

rubber vulcanizing machine

,

rubber vulcanizing equipment

Automatic Control Rubber Vulcanizing Machine for Vulcanization of Rubber



Application:



The Rubber Vulcanizing Machine is mainly used for the vulcanization of rubber products, like rubber seals, O-rings, rubber gaskets, rubber mats, rubber powder tiles, steel bonded rubber etc.

Double Layers Hydraulic Rubber Vulcanizing Press Machine Automatic Control 0



Machine Specifications:



  XLB350×350×2 XLB400×400×2 XLB600×600×2 XLB750×850×2
Total Pressure (MN) 0.25 0.5 1 1.6
Platen size (mm) 350*350 400*400 600*600 750*850
Plate Distance (mm) 125 150 125 200
Working Layer NO. 2 2 2 2
Unit Area Pressure(Mpa) 2.04 3.13 2.77 2.51
Plunger Stroke (mm) 250 300 250 400
Heating Mode Electric Electric/Steam Electric/Steam Electric/Steam
Motor Power (kw) 2.2 2.2 2.2 3
Overall dimension: (L×W×H) (mm) 1400×480×1380 1600×500×1480 1880×720×1680 2250×1200×2200



Machine introduction:



Reasonalbe design of switches for easy operation.

Double Layers Hydraulic Rubber Vulcanizing Press Machine Automatic Control 1



Semi-closed hydraulic station can effectively prevent dust.

Double Layers Hydraulic Rubber Vulcanizing Press Machine Automatic Control 2



Welcome to visit our factory!

Double Layers Hydraulic Rubber Vulcanizing Press Machine Automatic Control 3
