Column Structure Rubber Molding Press Machine With Mold Manual / Automatic Sliding System

Column Structure Rubber Molding Press Machine With Mold Manual / Automatic Sliding System
Column Structure Rubber Molding Press Machine With Mold Manual / Automatic Sliding System
Column Structure Rubber Molding Press Machine With Mold Manual / Automatic Sliding System Column Structure Rubber Molding Press Machine With Mold Manual / Automatic Sliding System Column Structure Rubber Molding Press Machine With Mold Manual / Automatic Sliding System Column Structure Rubber Molding Press Machine With Mold Manual / Automatic Sliding System

Large Image :  Column Structure Rubber Molding Press Machine With Mold Manual / Automatic Sliding System

Product Details:
Place of Origin: QINGDAO CHINA
Brand Name: RUNNING
Certification: ISO CE
Model Number: XLB-D/Q series
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Negotiation
Packaging Details: pallet
Delivery Time: 15~21days
Payment Terms: T/T, L/C
Supply Ability: 50sets/month

Column Structure Rubber Molding Press Machine With Mold Manual / Automatic Sliding System

Description
Application: Rubber Molded Product Making Machine Clamping Force: 25T~3000T
Control Mode: Manual, Relay Or PLC Automatic Control
High Light:

rubber vulcanizing machine

,

rubber vulcanizing equipment

Hot sale Rubber Molding Press Machine with Mold manual/automatic sliding system, Rubber Molded Product Press Machine



Application:



Rubber Molding Press is used for vulcanizing various kinds of rubber and plastic mould products as well as non-mould products. Like rubber seals, O-ring, rubber gasket, Condenser seal, rubber-steel bonded products, rubber mats, rubber tiles, rubber conveyor belts, silicone rubber products and synthetic rubber products etc.

Column Structure Rubber Molding Press Machine With Mold Manual / Automatic Sliding System 0



Introduction:



1.This machine is column structure, including main machine, hydraulic station, electric controlling cabinet. Main machine is composed by base, plunger piston, platform, beam, automatic mould pushing-out device and compulsory mould opening device.
2.Under the control of PLC, this machine achieves automatic mould closing, vulcanization timing, exhausting time and frequency setting, mould opening, mould pushing, and so on.
3.The mixing chamber is a combined configuration, which is convenient for assembling, disassembling and maintaining. The drop-door discharge device is driven by two reciprocating oil cylinder which directly pull the locking plate to lock the discharge door. The device provides fast discharging and reliable airproof.

Column Structure Rubber Molding Press Machine With Mold Manual / Automatic Sliding System 1
4. The rotors are supported by rolling bearings, which are easy to maitain and have a long service life.
5.The transmission system adopts a hard facing gear reducer, which has a compacted structure with higher transmission effciency, lower noise and longer service life.
6.The pressing ram device may be driven by pneumatic cylinder or oil cylinder to press onto the mixing materials to force them equally mixed so as to increase productive effciency. Mated with the electric controller, the pressing ram device can automatically add pressure, release pressure or just keep floating.
7.Both manual and automatic modes are arranged to operate PLC electric system. It is easy to exchange the modes and reliable to operate the controller.



Technical parameters:



Item XLB750×850×2/4 XLB-Q900×900×2 XLB-DQ1200
×1200×2
XLB-DQ1300
×2000×1
XLB-Q1200
×2500×1
XLB-Q1500
×2000×1
XLB-Q2000
×3000×1
Total pressure (MN) 1.60 2.00 3.15 5.60 7.50 10.00 18.00
Daylight (mm) 200 300 200 400 400 400 400
Platen Layers 2-4 2 2 1 1 1 1
Unit area pressure of hot plate(Mpa) 2.51 2.47 2.19 2.15 2.5 3.33 3
Piston stroke (mm) 400 400 400 400 400 400 400
Heating mode Electricity/
Stream
Stream 22 21.5 25 33.5 30
Main motor power (KW) 3 5.5 3 8 9.5 11 26
Size: (L × W × H) (mm) 2250×1200×2200 1400×900
×2400
(Mainframe)
1685×1320×2450 2000×1860×2500 2560×1700×2780 2810×1550×3325 2900×3200×2860



Photos:

Column Structure Rubber Molding Press Machine With Mold Manual / Automatic Sliding System 2Column Structure Rubber Molding Press Machine With Mold Manual / Automatic Sliding System 3Column Structure Rubber Molding Press Machine With Mold Manual / Automatic Sliding System 4



Packaging:



Column Structure Rubber Molding Press Machine With Mold Manual / Automatic Sliding System 5
