|Weight:||300kgs||Control Type:||Remote Control|
|Material Of Bush:||Non-woven Fabric||Origin Of Bush:||USA|
Intelligent Platen Cleaning Machine,
Nonwoven Brush Platen Cleaning Machine,
Remote Platen Cleaning Machine
Intelligent Light Weight Conveyor Belt Vulcanizing Press Heating Platen Cleaning Machine
This machine is aimed at improving the efficiency of cleaning the pot and avoiding the danger caused by manual cleaning. On the basis of absorbing foreign advanced experience and the professors of Qingdao University of Science and Technology, we have developed a domestic conveyor belt industry's most advanced pot scrubber through long-term practice. The appearance and structure of the equipment are accordance with the German Siempelkamp company.
Name: Intelligent Light Weight Conveyor Belt Vulcanizing Press Heating Platen Cleaning Machine
1. The machine adopts hydraulic control of the lifting of the roller brush and the whole machine. The pressure between the roller brush and the hot plate of the hydraulic wall belt pressure relief device is unchanged, thus ensuring the uniform force of the hot plate. The upper and lower hot plates can be cleaned at the same time, the decontamination ability is strong without damaging the hot plates, and the work efficiency is extremely high. The transmission method of the roller brush is belt transmission, and the transmission pulleys are all tension type, which is easy to disassemble. The whole machine is controlled by remote remote control, which is convenient for operation and guarantees safe operation by operators.
2. This cleaning machine is more than 20 times more efficient than manual cleaning. It is also engraves the old disc type emery cloth cleaning machine, which causes the misunderstanding of the vicious circle of higher and lower hot plates, which is time-consuming and labor-intensive. The sundries are removed and the hot plate is maintained, which can extend the life of the hot plate. For example, long-term use of the old hot plate can play a certain role in repairing.
3. The machine adopts rolling brush to rotate and move in parallel, and integrates grinding and polishing. The surface of the wiped hot plate is smooth and smooth, and the finish is extremely high, so that the surface quality of the product is greatly improved, the downtime is shortened, and the production efficiency is increased. It is the indispensable and ideal supporting equipment for the plate vulcanizing machine.
|Power Supply||Base on customer’s requirement|
|Effective cleaning width||600mm|
|Lifting height of roller brush||0-350mm|
|Brush roller speed||3000r/min|
|Control Type||Remote control|
1. Roller brush: The roller brush of this machine is made of 3M non-woven material imported from the United States, with a hardness of 90 and a turning indicator, over size is 125mmX50mmX450mm
2. Motor: Two roller brush motors adopt aluminum shell custom 3KW motors to reduce the overall weight of the equipment. The equipment has a thermal protection system to prevent the motor from heating and burning the motor. The walking motor adopts a Taiwan imported brand, and the operating speed is adjustable through the button. One hydraulic station motor is imported from Taiwan, with low noise, stable and reliable operation.
3. Hydraulic station: The hydraulic system and cylinder adopt Yuci Yuken hydraulic system, which runs smoothly and reliably, and uses high-pressure oil pipe and copper pipe connection to prevent oil leakage.
4. Appearance of the equipment: The equipment cover and the dirt baffle are made of 2mm stainless steel, which is beautiful and reliable to prevent the dirt of the pot scrubber from entering into the pot scrubber and causing electrical parts to short-circuit. All processed parts of the equipment are blackened to prevent rust.
5. Electrical part: The electrical part adopts Schneider brand, which is stable and reliable. All electrical appliances and the receiving part of the remote control are individually sealed to prevent short circuits caused by debris.
6. Remote control: The remote control part is made by Nanjing Bojiao Electronics Company, stable and reliable, and the remote control distance is 50 meters.
7. Lifting of the whole machine: The lifting of the whole machine adopts hydraulic lifting, with 4 hydraulic cylinders, and bearing structure at the bottom. When the equipment is raised, it only needs to be pushed gently.
8. Pressure relief system: the equipment lifting cylinder drives the roller brush up and down. When the roller brush motor starts, it gently approaches the hot plate to wipe the pot. When the lifting cylinder is close to the hot plate and reaches a certain pressure, the cylinder automatically releases pressure to prevent the roller brush from lifting the arm. Excessive pressure may cause damage to the roller brush.
9. Oil unloading: The equipment has an oil unloading port. When the equipment hydraulic station needs to replace the hydraulic oil, the oil can be unloaded without opening the cover.
10. Pulleys: All pulleys of the equipment adopt tension-type pulleys, which are easy to disassemble.
11. V-belt: All V-belts of the equipment adopt the Korean Samsung brand and are reliable in temperature setting.
12. Power connection: Part of the connection between the power supply and the equipment adopts a fixed connection with aviation plugs, which is stable, reliable, convenient and not easy to damage.
