Product Details:
|
| Weight: | 300kgs | ||
|---|---|---|---|
| High Light: | 1.7m/Min Cleaning Heat Press Platen,Conveyor Belt Cleaning Heat Press Platen,Platen Conveyor Belt Vulcanizing Press |
||
1.7m/Min Cleaning Heat Press Platen Conveyor Belt Vulcanizing Press
1. Function and characteristic
This machine mainly consists of hydraulic power driving unit ,cleaning roller driving unit ,cleaning roller brushing unit and electrical control unit .
2. Structure and technical parameter
This machine consists of frame, hydraulic section, moving section, brush driving section, electric control section etc.
1.1 Hydraulic sectione contains of hydraulic station, valve control system, pipe, brush up&down cylinders, machine up&down cylinders etc.
1.2 Moving section contains of adjustable-speed motor, speed controller, chain wheel, tension wheel, moving wheel etc.
1.3 Brush driving section contains of motor, belt, belt wheel,belt tension wheel, brush fixed shaft.
1.4 Electrical system contains of convenience receptacle, contractor, intermediate relay, remote control receiving system, remote control handle etc.
3. Technical parameter
| Voltage | AC, 3-380V (Three-Phase | |
| Machine power | 6.5KW | |
| Cleaning width | 600(mm) | |
| Brush lifting height | 0-350(mm) | |
| Brush rotate speed | 3000r/min | |
| Moving speed | 0-1.7m/min | |
| Control method | Remote control handle | |
| Weight | 300kg | |
| Dimension | 1400x750x240(mm) |
4. Lubrication and Maintenance
1. Bearing which on both ends of the brush fixed shaft should be checked regularly. Oil in 3# lithium lubricating grease(Running 50 hours).
2. Brush motor bearing should be checked regularly. Oil in 3# lithium lubricating grease(Running 100 hours).
3. Bearing which on both ends of the moving wheels should be checked regularly. Oil in 3# lithium lubricating grease(Running 500 hours).
4. Hydraulic system should be checked regularly. Oil in 46# hydraulic oil.
5. Host Machine
