Product Details:
|
Name: | Hot Feed Rubber Extruder | Model: | XJL-250 |
---|---|---|---|
Application: | Rubber Profiles Manufacturing | Max. Screw Rotate Speed: | 40r/min |
Main Motor: | 110kw | Feeding Motor: | 7.5kw |
Cutting Motor: | 1.5kw | Hydraulic Driving Motor: | 3.7kw |
Capacity: | 1500-2000kg/h | ||
High Light: | 2000kg/H Hot Feed Rubber Extruder,1500kg/H Hot Feed Rubber Extruder,Profiles Hot Feed Rubber Extruder |
1500-2000kg/H Hot Feed Rubber Extruder Rubber Profiles Manufacturing
Hot Feed Rubber Extruder is one of the most widely used important equipment. It is mainly used in tire tread, gaskets, tape, and another rubber extrusion.
Hot Feed Rubber Extruder is energy saving, high productivity , good plasitcization and refined glue quality characteristic.
Structural Features:
1. Compared to traditional technology, through replace the function of rubber mixing mill during rubber compound mixing, save labors and greatly decreased production cost.
2. By using double strainer head, hydraulic push-pull to replace the filter, rapid operation, no rubber leakage, saving time and energy.
3. The screw rotating speed is adjustable which can match with the front and rear machines, improving resource utilization, safety and energy conservation.
4. Specialize designed hard tooth gear reducer adopted, low noise and long service life.
5. Barrel, screw made by qualified alloy steel 38CrMoAlA, through quenching and nitriding, durable wear.
6. Can equip auto cutting rubber device to decrease the labor intensity.
Technical Parameters:
Type | XJL-150YQ | XJL-200YQ | XJL-250YQ |
Screw diameter(mm) | 150 | 200 | 250 |
Length-diameter ratio of the screw | 6:1 | 5.5:1 | 5:1 |
Screw speed(r/min) | 49 | 5-49 | 5-39 |
Max production capacity(kg/h) | 600 | 1000 | 2000 |
Driving power(kw) | 37 | 75 | 110 |
Machine weight(T) | 3 | 5 | 6.2 |
Overall dimension(mm) | 2690*990*1400 | 3695*1255*1511 | 4102*1365*1600 |
Machine delivery:
