Large Image :  Motorcycle / Bicycle Tires Hydraulic Curing Press Multi Layer 800mm Platen

Product Details:
Place of Origin: QINGDAO CHINA
Brand Name: RUNNING
Certification: ISO CE
Model Number: LLY-800
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: $28,000~$38,000
Packaging Details: Standard shipping package
Delivery Time: 21~30days
Payment Terms: T/T, L/C
Supply Ability: 100sets/month

Motorcycle / Bicycle Tires Hydraulic Curing Press Multi Layer 800mm Platen

Description
Usage: Making Tires Model: YLL-800
Working Layer: 4-5 Layers Plate Diameter: 800mm
Total Pressure: 90T Plunger Diameter: 240mm
Steam Working Pressure: 0.6-0.8Mpa Control: PLC Automatic
High Light:

Bicycle Tires Hydraulic Curing Press

,

Multilayer Hydraulic Curing Press

,

800mm Platen Tire Curing Machine

2.50-17 Motorcycle / Bicycle Tires Multi-layer 800mm Platen Hydaraulic Curing Press Machine



What is tire curing?



Tire curing is a high-temperature and high-pressure batch operation in which the uncured tire is placed into a mold at a specified temperature. After the mold is closed, the rubber compound flows into the mold which forms the tread details and sidewall. The mold cannot be opened until the curing reaction is completed.



Motorcycle / Bicycle Tires Hydraulic Curing Press Multi Layer 800mm Platen 0



Application:



For various electric vehicles, motorcycle tire curing, except man operated tire loading and removal, the entire curing process is automatically controlled.



Our machine is fully automatic control, compact, small footprint, simple workers, high productivity, low cost devices, easy maintenance, low maintenance cost. we provide technical training, machine specific details, Can be customized according to customer requirement



Motorcycle / Bicycle Tires Hydraulic Curing Press Multi Layer 800mm Platen 1



Machine specifications of tire curing press machine:



Type YLL-600 YLL-1000 YLL-1400 YLL-1600 YLL-2000
Total pressure(KN) 600 1000 1400 1600 2000
Working layer number 2 2 2 2 2
Steam chamber internal dia.(MM) 820 830 1050 1150 1450
Piston(MM) 250 285 340 360 400
High Pressure(Mpa) 13 16 15.5 16 14
Low pressure(Mpa) 5 5 5 5 5
Pressure in bladder(Mpa) 1.5 2.1 2.1 2.1 2.1
Steam-Working pressure(Mpa) 0.6-0.8 0.6-0.8 0.6-0.8 0.6-0.8 0.6-0.8
Overall dimension 1200×900×2400 1200×900×2358 1360×1050×3820 1410×1060×3500 1500×1500×3200
Weight (Kg) 3200 4500 6000 7000 8000


Motorcycle / Bicycle Tires Hydraulic Curing Press Multi Layer 800mm Platen 2



For increasing production capacity, the machine can be 4-5 working layers, means you can get 4-5 pcs tires per batch.
And there can be 8, 10 or 12 working stations using one control cabniet & one hydraulic station together, which will reduce the cost.



Motorcycle / Bicycle Tires Hydraulic Curing Press Multi Layer 800mm Platen 3



Our machine at tire manufacturing factory:



Motorcycle / Bicycle Tires Hydraulic Curing Press Multi Layer 800mm Platen 4



Related machines:



Rubber Mixing Mill

Motorcycle / Bicycle Tires Hydraulic Curing Press Multi Layer 800mm Platen 5
