3 Roll Calender And Extruder Machine For Rubber Sheet Extruding And Calendering

3 Roll Calender And Extruder Machine For Rubber Sheet Extruding And Calendering
3 Roll Calender And Extruder Machine For Rubber Sheet Extruding And Calendering

Large Image :  3 Roll Calender And Extruder Machine For Rubber Sheet Extruding And Calendering

Product Details:
Place of Origin: CHINA
Brand Name: RUNNING
Certification: CE,SGS,ISO
Model Number: 450X1400
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Delivery Time: 35DAYS
Payment Terms: L/C, T/T, D/P, D/A
Supply Ability: 20 SETS/M

3 Roll Calender And Extruder Machine For Rubber Sheet Extruding And Calendering

Description
Motor Power: 55KW WORK LENGTH: 1400MM
Control Type: PLC Warranty: 5years
After-sales Service Provided: Engineers Available To Service Machinery Overseas Certification: CE ISO SGS
Lubrication: Grease Or Oil Roller: Cold Hard Cast Iron
High Light:

three roll rubber calender machine

,

four roll rubber calender

3 Roll Calender And Extruder Machine For Rubber Sheet Extruding And Calendering

Rubber calendering machine is mainly used for:

Textile (cloth, canvas, etc.) of glue and eraser; steel cord adhesive; rubber compression and pressure type; cord attached to the fit of the isolation film and multilayer film.

Configuration

1. Rolls: Chilled Alloy Cast Iron rolls with surface hardness 68~72HS. The Rolls are mirror finished & polished, duly grinded and are hollowed for cooling or heating.

2. Roll Clearance Adjusting Unit: Nip adjustment at two roller ends is done manually using two separate screws attached to the brass housing body.

3. Roll Cooling: Universal Rotary joints with inner Spray pipes with Hoses and Headers. Piping is complete up to supply pipe terminal.

4. Journal Bearing Housing: Heavy Duty Steel Casting Housing fitted with Anti Friction Roller Bearings.

5. Lubrication: Full Automatic Grease lubrication pump for Anti Friction Roller Bearings fitted in dust sealed housing.

6. Stand Frame & Apron: Heavy Duty Steel Casting.

7. Gearbox: Hard-tooth reduction gearbox, GuoMao brand.

8. Base Frame: Common base frame heavy duty, Steel channel and MS plate fabricated accurately machined on which whole machine with Gearbox and motor are fitted.

9. Electric Panel: Star Delta Electric operating panel with Auto Reversing, Voltmeter, Ampere, Overload protection relay, 3 Phase Indicator and Emergency Stop Switch.



Parameter/model XY-3-250 XY-3-360 XY-3-400 XY-3-450 XY-3-560 XY-3-610 XY-3-810
Roll diameter(mm) 250 360 400 450 560 610 810
Roll working length (mm) 720 1120 1200 1400 1650 1730 2130
Ratio of rubber speed 1:1 1:1 1:1 1:1.5:1 1:1.5:1 1:1.4:1 1:1:1
Roll speed (m/min) 2-15.9 3-20 3-26 2.6-26.2 3-30 5.4-54 3-30
Nip adjust range (mm) 0-6 0-10 0-10 0-10 0-15 0.5-25 0.2-25
Motor power (KW) 22 45 55 75 110 160 132x3
Weight (KG) 5500 14000 18000 21000 35000 42000 110000



3 Roll Calender And Extruder Machine For Rubber Sheet Extruding And Calendering 03 Roll Calender And Extruder Machine For Rubber Sheet Extruding And Calendering 13 Roll Calender And Extruder Machine For Rubber Sheet Extruding And Calendering 2
